Series 149 Detroit Diesel Engines

ELECTRIC GOVERNOR - groups: 2.6566 - 2.6610

2.6505 - 2.6693 Electric Governor.jpg - Diagram

Page: 96

Information Abbreviations Alphabetical Index Group Index

	Part No.	Description	Group	Ref#	8V	12V	16V	20V	Price	QOH
Details	179796	Bolt, 1/4"-20 X 7/8"; (Option Type #'s 25, 27, 28, 30, 36, 95)	2.6566	00	1	1	1	1	$0.30	1
Details	5173874	Lever; (Option Type #"s 25, 27, 28, 30, 36, 95)	2.6566	00	1	1	1	1	$132.21	34
Details	103319	Lockwasher, 1/4"	2.6566	00	A/R	A/R	A/R	A/R	$0.39	100+
Details	23516113	Control Assembly; (Option Type #'s 19, 20, 48, 50, 58, 60, 64, 65)	2.6570	00	1	1	1	1	$1,644.62	1
	8924120	Control Assembly; (Dyni 283008); (Option Type #3)	2.6570	00	1	1	1	1		0
	8926946	Control Assembly; (Dyni 10003-002); (Option Type #'s 10, 22, 9) (OBSOLETE)	2.6570	00	1	1	1	1	OBSOLETE	0
Details	23516114	Kit, Electronic Governor	2.6570	00	A/R	A/R	A/R	A/R	$2,261.05	1
Details	23516113	Control Assembly; (Option Type #'s 19, 20, 48, 50, 58, 60, 64, 65)	2.6570	00	1	1	1	1	$1,644.62	1
Details	23502869	Harness Assembly, 2-Wire	2.6570	00	1	1	1	1	$325.49	0
Details	23502872	Harness Assembly, 3-Wire	2.6570	00	1	1	1	1	$468.03	0
Details	23502470	Potentiometer, Speed Select	2.6570	00	1	1	1	1	$197.14	1
	Note: Next Seven Items Are For Option Type #3.
	8925210	Amplifier, Actuator Control Assembly	2.6571	00	1	1	1	1		0
	8925211	Module, Pneumatic Speed Decoding #1	2.6571	00	1	1	1	1		0
	8925212	Module, Actuator Input #2	2.6571	00	1	1	1	1		0
	8925213	Module, Actuator Output #3	2.6571	00	1	1	1	1		0
	8925214	Module, Load Control #6	2.6571	00	1	1	1	1		0
	8924121	Transducer Assembly; (Dynt 40005)	2.6575	00	1	1	1	1		0
	8924122	Harness Assembly	2.6580	00	1	1	1	1		0
Details	23502869	Harness Assembly, 2-Wire	2.6585	00	A/R	A/R	A/R	A/R	$325.49	0
	8924124	Cable Assembly	2.6585	00	A/R	A/R	A/R	A/R		0
Details	23502872	Harness Assembly, 3-Wire	2.6590	00	A/R	A/R	A/R	A/R	$468.03	0
	8924123	Harness Assembly	2.6590	00	A/R	A/R	A/R	A/R		0
Details	8927966	Harness Assembly; 8V; (Option Type #22)	2.6591	00	1				$583.23	0
Details	8927967	Harness Assembly; 12V; (Option Type #9)	2.6591	00		1			$564.03	0
Details	8927968	Harness Assembly; 16V; (Option Type #10)	2.6591	00			1		$598.41	0
Details	8923172	Magnetic Pickup Assembly	2.6595	00	A/R	A/R	A/R	A/R	$351.17	0
Details	8923744	Pickup Assembly	2.6595	00	A/R	A/R	A/R	A/R	$582.34	0
Details	103345	Washer 5/8 X 1.325 X 0.097, Stl. Pln.	2.6595	00	A/R	A/R	A/R	A/R	$0.40	0
Details	23515367	Washer,Threadseal 5/8"	2.6595	00	A/R	A/R	A/R	A/R	$6.84	0
Details	8927886	Cover (OBSOLETE)	2.6610	00	A/R	A/R	A/R	A/R	OBSOLETE	1
Details	443603	Bolt, 1/4"-20 X 3/4"; (12.9001)	2.6610	00	A/R	A/R	A/R	A/R	$0.99	29
Details	9417926	Bolt, 1/4"-20 X 3/4"; W/Lockwasher; (12.9001)	2.6610	00	A/R	A/R	A/R	A/R	$8.70	7
	GROUP 2.6610 CONTINUED ON NEXT PAGE
