Series 60 Detroit Diesel Engines

SUPER ENGINE OVERHAUL KIT CONTENTS FOR
PART #23532572 - group: 12.8725

12.8725 Super Engine Overhaul Kits.jpg - Diagram
Page: 304
Part No. Description GroupRef#11.1L12.7L14.0L Price QOH
Details 23532572 Super O/H Kit; 15:1 C/R; TLC Bianitic Liner; 2.5mm
Ring, 47mm Bearing
Superceded... Click 'Details' for replacement.
12.872500A/R0
Details 23520644 Arm & Roller Assembly, Intake Rocker; W/Out Oil Hole 12.8725006$95.930
Details View Images 23523174 Arm & Roller Assembly, Exhaust Rocker; W/Out Oil Hole 12.8725006$196.350
View Images 23525567 Head Assembly; 3 Bolt Thrust Plate W/Race Track Seal 12.87250010
Details 23532555 Cylinder Kit; 15:1 TLC Bainitic Liner; 2.5mm Ring
Groove; S50/60
Superceded... Click 'Details' for replacement.
12.87250067
Details 23516681 Skirt, Crosshead Piston; (Roc) 12.8725001$68.140
Details View Images 8929013 Seal, Crevice 12.8725001$2.5112
Details 8929087 Pin, Piston 12.8725001$28.190
Details View Images 8929176 Seal, D-Ring 12.8725002$4.6412
Details View Images 8929337 Bolt, M14 X 1.5 X 60; 12 Point 12.8725002$2.7914
Details 8929844 Ring, Piston Top; 2.5mm Keystone 12.8725001$6.040
Details View Images 8929845 Ring, Piston Bottom; Keystone 12.8725001$7.899
Details View Images 23504942 Bushing, Top Piston Dome; 3 Piece 12.8725001$13.823
Details View Images 23515500 Ring, Piston Oil Control; Crosshead Piston 12.8725001$9.841
View Images 23519558 Bearing, Piston; (Lower); Pressure Fit; S50/60 (OBSOLETE) 12.8725002OBSOLETE2
Details View Images 23529379 Expander, Oil Control Ring; Spr Piston 12.8725001$4.251
4PM037E Skid 12.87250010
23529367 Dome Assembly; 15:1 Crosshead Piston 12.87250010
23531502 Liner, Cylinder; Bainitic; 12L (OBSOLETE) 12.8725001OBSOLETE0
Details View Images 8929854 Arm Assembly, Injector Rocker; Steel Roller 12.8725006$316.2585
Details View Images 8929130 Gasket, Accessory Cover 12.8725002$1.7513
Details View Images 8929299 Gasket, Front Accessory 12.8725002$3.2017
Details View Images 8929529 Gasket, Turbo Exhaust Inlet 12.8725001$2.0428
Details View Images 23515145 Gasket; (1.5040) 12.8725001$1.7632
Details View Images 23517875 Gasket, Air Intake Manifold 12.8725003$4.8110
Details View Images 23533983 Gasket, 3 Piece Exhaust Manifold; SST Thermoglide 12.8725003$5.807
Details View Images 5132155 Seal, Thermostat
Superceded... Click 'Details' for replacement.
12.8725002155
Details View Images 5150193 Gasket, Fuel Pump To Drive Assembly; (5.1010) 12.8725001$0.73220
Details View Images 5182977 Ring Seal; (3.3055) 12.8725001$0.3018
Details View Images 8929253 Seal Ring, 0.139" X 4.609" I.D.; (2.2280) 12.8725002$4.4515
Details View Images 8929285 Gasket, Turbo Oil Drain Tube 12.8725001$0.7116
Details View Images 8929302 Gasket; 4 Hole; (4.5007) 12.8725001$0.568
Details View Images 8929740 Seal Ring, 0.134 X 0.074 X 0.480 I.D. 12.8725003$1.338
Details View Images 23505248 Gasket, Fuel Pump 12.8725001$1.3512
Details View Images 23521894 Seal, Camshaft Thrust Plate To Cylinder Head 12.8725001$4.179
Details View Images 23521935 Seal, Camshaft Thrust Plate 12.8725001$4.5410
Details View Images 23522975 Seal, Front Camshaft Cap 12.8725001$1.453
Details View Images 23528491 Seal, Camshaft Thrust Plate Perimeter 12.8725001$6.574
Details View Images 5141452 Seal Ring; (3.4143) 12.8725001$1.2914
Details View Images 8929280 Seal Ring 12.8725002$1.9334
Details View Images 8929289 Seal Ring 12.8725002$2.7615
Details View Images 8929340 O-Ring, By-Pass Filter 12.8725001$1.2322
Details View Images 8929341 O-Ring, Oil Filter 12.8725001$1.2527
Details View Images 8929342 O-Ring, Oil Filter Adaptor; (Figure "8") 12.8725001$2.2814
Details View Images 8929347 Gasket, To Block 12.8725002$1.3221
Details View Images 8929348 Gasket 12.8725001$2.2313
Details View Images 23505891 Seal Ring, Oil Pump Outlet 12.8725001$1.0113
Details View Images 23505892 Seal Ring, Oil Pump Inlet 12.8725001$1.1212
Details View Images 23508392 Seal Ring 12.8725004$2.3443
Details View Images 23532850 Seal Ring, By-Pass Filter Adaptor 12.8725001$2.999
Details View Images 23521111 Seal 12.8725002$1.908
Details View Images 5117269 Gasket 12.8725002$0.6416
Details View Images 8929158 Seal Ring, 0.139 X 5.359 I.D.; Round 12.8725001$3.7527
Details View Images 8929344 Gasket, To Pump; (4.1520) 12.8725002$0.83167
Details View Images 8929347 Gasket, To Block 12.8725001$1.3221
Details View Images 8929510 Seal Ring, Cover 12.8725001$2.26167
Details View Images 23505024 Seal, O-Ring; Water Pump Cover; Square Cut 12.8725001$1.5819
Details View Images 23505992 Gasket, Oil Inlet Tube To Pump 12.8725001$0.683
Details View Images 23520377 Seal Ring; W/Square Cut 12.8725001$1.9270
Details View Images 8929878 Thermostat Assembly; 190 Deg. Opening Temp.
Superceded... Click 'Details' for replacement.
12.872500216
23532045 Gasket, Cylinder Head; High Pressure 12.87250010
Details View Images 8929690 Bearing Set, Std. 12.8725007$5.56115
8929086 Shell, Camshaft Bearing; Half 12.87250020
Details View Images 23520818 Screw Assembly, Intake Valve; Adjustable; Unitized;
S50/60
12.87250012$12.1620
Details View Images 23520820 Screw Assembly, Injector Adjustable; Unitized; S50/60 12.8725006$13.3312
Details 23527000 Low N-Ox Instruction Envelope; S60 12.8725001$7.284
Details View Images 23530768 Bolt, M16 2.0 X 1.75; Large Hex 10.9; (12.9001) 12.87250038$2.47338
Details 23531605 Lower End Bearing Kit; 47mm Std. C/R Bearing 12.8725001$220.713
Details View Images 8929085 Crankshaft Thrust Washer 12.8725002$10.2116
Details View Images 5117269 Gasket 12.8725001$0.6416
Details View Images 8929344 Gasket, To Pump; (4.1520) 12.8725002$0.83167
Details View Images 8929347 Gasket, To Block 12.8725001$1.3221
Details View Images 23505992 Gasket, Oil Inlet Tube To Pump 12.8725001$0.683
Details 23515585 Shell, Lower Con Rod Bearing; S50/60 12.8725006$7.750
23515586 Shell, Upper Con Rod Bearing; Large; S50/60 12.87250060
Details 23533252 Shell, Main Bearing, Lower 12.8725007$22.200
Details 23533259 Shell, Main Bearing, Upper 12.8725006$22.200
Details 23533263 Shell, Main Bearing, Upper; (Thrust) 12.8725001$1.960
Details 23534149 Screw Assembly, Valve; Adjustable; Unitized S50/60
Superceded... Click 'Details' for replacement.
12.872500120
GROUP 12.8725 CONTINUED ON NEXT PAGE
