Series 60 Detroit Diesel Engines

SUPER ENGINE OVERHAUL KIT CONTENTS FOR
PART #23532589 - group: 12.8725

12.8725 Super Engine Overhaul Kits.jpg - Diagram

Page: 312

Information Abbreviations Alphabetical Index Group Index

	Part No.	Description	Group	Ref#	12.7L	Price	QOH
Details	23532589	Super O/H Kit; 15:1 C/R; TLC Bianitic Liner; 2.5mm Ring; 47mm Bearing; +0.020 H-Valves Superceded... Click 'Details' for replacement.	12.8725	00	A/R		0
Details	23513939	Arm Assembly, Injector Rocker; Ceramic Roller; Honed Bushing Superceded... Click 'Details' for replacement.	12.8725	00	6		0
Details	23520644	Arm & Roller Assembly, Intake Rocker; W/Out Oil Hole	12.8725	00	6	$95.93	0
Details	23523174	Arm & Roller Assembly, Exhaust Rocker; W/Out Oil Hole	12.8725	00	6	$196.35	0
Details	23525566	Head Assembly; 3 Bolt Thrust Plate W/Race Track Seal Superceded... Click 'Details' for replacement.	12.8725	00	1		0
Details	23532557	Cylinder Kit; 15:1; TLC Bainitic Liner; 2.5mm Ring Superceded... Click 'Details' for replacement.	12.8725	00	6		10
Details	23516681	Skirt, Crosshead Piston; (Roc)	12.8725	00	1	$69.83	0
Details	8929013	Seal, Crevice	12.8725	00	1	$5.08	16
Details	8929087	Pin, Piston	12.8725	00	1	$34.80	0
Details	8929176	Seal, D-Ring	12.8725	00	2	$5.55	12
Details	8929337	Bolt, M14 X 1.5 X 60; 12 Point	12.8725	00	2	$5.31	14
Details	8929844	Ring, Piston Top; 2.5mm Keystone	12.8725	00	1	$12.97	0
Details	8929845	Ring, Piston Bottom; Keystone	12.8725	00	1	$16.69	9
Details	23504942	Bushing, Top Piston Dome; 3 Piece	12.8725	00	1	$17.25	3
Details	23515500	Ring, Piston Oil Control; Crosshead Piston	12.8725	00	1	$12.00	1
	23519558	Bearing, Piston; (Lower); Pressure Fit; S50/60 (OBSOLETE)	12.8725	00	2	OBSOLETE	2
Details	23529379	Expander, Oil Control Ring; Spr Piston	12.8725	00	1	$4.25	1
	4PM037E	Skid	12.8725	00	1		0
	23529370	Dome Assembly; 15:1 Crosshead Piston	12.8725	00	1		0
	23531502	Liner, Cylinder; Bainitic; 12L (OBSOLETE)	12.8725	00	1	OBSOLETE	0
Details	8929130	Gasket, Accessory Cover	12.8725	00	2	$1.88	13
Details	8929299	Gasket, Front Accessory	12.8725	00	2	$3.26	15
Details	8929529	Gasket, Turbo Exhaust Inlet	12.8725	00	1	$2.75	22
Details	23515145	Gasket; (1.5040)	12.8725	00	1	$2.49	41
Details	23517875	Gasket, Air Intake Manifold	12.8725	00	3	$4.85	10
Details	23533983	Gasket, 3 Piece Exhaust Manifold; SST Thermoglide	12.8725	00	3	$6.49	25
Details	5132155	Seal, Thermostat Superceded... Click 'Details' for replacement.	12.8725	00	2		55
Details	5150193	Gasket, Fuel Pump To Drive Assembly; (5.1010)	12.8725	00	1	$0.78	422
Details	5182977	Ring Seal; (3.3055)	12.8725	00	1	$1.74	21
Details	8929253	Seal Ring, 0.139" X 4.609" I.D.; (2.2280)	12.8725	00	2	$4.45	15
Details	8929285	Gasket, Turbo Oil Drain Tube	12.8725	00	1	$0.71	15
Details	8929302	Gasket; 4 Hole; (4.5007)	12.8725	00	1	$0.78	8
Details	8929740	Seal Ring, 0.134 X 0.074 X 0.480 I.D.	12.8725	00	3	$1.38	8
Details	23505248	Gasket, Fuel Pump	12.8725	00	1	$1.35	37
Details	23521894	Seal, Camshaft Thrust Plate To Cylinder Head	12.8725	00	1	$4.25	9
Details	23521935	Seal, Camshaft Thrust Plate	12.8725	00	1	$5.23	11
Details	23522975	Seal, Front Camshaft Cap	12.8725	00	1	$1.48	3
Details	23528491	Seal, Camshaft Thrust Plate Perimeter	12.8725	00	1	$6.57	5
Details	5141452	Seal Ring; (3.4143)	12.8725	00	1	$1.85	13
Details	8929280	Seal Ring	12.8725	00	2	$2.65	36
Details	8929289	Seal Ring	12.8725	00	2	$2.88	16
Details	8929340	O-Ring, By-Pass Filter	12.8725	00	1	$2.15	22
Details	8929341	O-Ring, Oil Filter	12.8725	00	1	$1.48	27
Details	8929342	O-Ring, Oil Filter Adaptor; (Figure "8")	12.8725	00	1	$2.51	15
Details	8929347	Gasket, To Block	12.8725	00	2	$1.32	22
Details	8929348	Gasket	12.8725	00	1	$2.29	14
Details	23505891	Seal Ring, Oil Pump Outlet	12.8725	00	1	$1.45	12
Details	23505892	Seal Ring, Oil Pump Inlet	12.8725	00	1	$1.14	11
Details	23508392	Seal Ring	12.8725	00	4	$2.37	43
Details	23532850	Seal Ring, By-Pass Filter Adaptor	12.8725	00	1	$3.48	9
Details	5117269	Gasket	12.8725	00	2	$1.00	22
Details	8929158	Seal Ring, 0.139 X 5.359 I.D.; Round	12.8725	00	1	$3.75	28
Details	8929344	Gasket, To Pump; (4.1520)	12.8725	00	2	$0.85	169
Details	8929347	Gasket, To Block	12.8725	00	1	$1.32	22
Details	8929510	Seal Ring, Cover	12.8725	00	1	$3.12	168
Details	23505024	Seal, O-Ring; Water Pump Cover; Square Cut	12.8725	00	1	$1.66	19
Details	23505992	Gasket, Oil Inlet Tube To Pump	12.8725	00	1	$1.86	2
Details	23520377	Seal Ring; W/Square Cut	12.8725	00	1	$3.05	70
	23532045	Gasket, Cylinder Head; High Pressure	12.8725	00	1		0
Details	8929690	Bearing Set, Std.	12.8725	00	7	$7.63	115
	8929086	Shell, Camshaft Bearing; Half	12.8725	00	2		0
Details	8929878	Thermostat Assembly; 190 Deg. Opening Temp. Superceded... Click 'Details' for replacement.	12.8725	00	2		14
Details	23519906	Lower End Bearing Kit; 47mm 0.020 U.S C/R Bearing	12.8725	00	1	$261.28	0
Details	8929085	Crankshaft Thrust Washer	12.8725	00	2	$11.74	14
Details	5117269	Gasket	12.8725	00	1	$1.00	22
Details	8929344	Gasket, To Pump; (4.1520)	12.8725	00	2	$0.85	169
Details	8929347	Gasket, To Block	12.8725	00	1	$1.32	22
Details	23505992	Gasket, Oil Inlet Tube To Pump	12.8725	00	1	$1.86	2
Details	23515589	Shell, Large Lower Con Rod Bearing; 0.508 U.S.	12.8725	00	6	$14.42	0
Details	23515590	Shell, Large Upper Con Rod Bearing; 0.508 U.S.	12.8725	00	6	$14.42	0
Details	23533250	Shell, Main Bearing, Lower; 0.508 U.S.	12.8725	00	7	$22.20	0
Details	23533257	Shell, Main Bearing, Upper; 0.508 U.S.	12.8725	00	6	$22.20	0
Details	23533261	Shell, Main Bearing, Upper #6; 0.508 U.S.	12.8725	00	1	$22.20	0
Details	23520818	Screw Assembly, Intake Valve; Adjustable; Unitized; S50/60	12.8725	00	12	$13.05	26
Details	23520820	Screw Assembly, Injector Adjustable; Unitized; S50/60	12.8725	00	6	$15.46	15
Details	23527000	Low N-Ox Instruction Envelope; S60	12.8725	00	1	$7.28	4
Details	23530768	Bolt, M16 2.0 X 1.75; Large Hex 10.9; (12.9001)	12.8725	00	38	$3.66	209
Details	23534149	Screw Assembly, Valve; Adjustable; Unitized S50/60 Superceded... Click 'Details' for replacement.	12.8725	00	12		0
	GROUP 12.8725 CONTINUED ON NEXT PAGE
