Series 60 Detroit Diesel Engines

BASIC ENGINE OVERHAUL KIT CONTENTS FOR
PART #23532581 - group: 12.8730

12.8730 Basic Engine Overhaul Kits.jpg - Diagram
Page: 323
Part No. Description GroupRef#11.1L12.7L14.0L Price QOH
Details 23532581 Basic Overhaul Kit; TLC Bianitic Liner; 3.5mm Ring Groove
Superceded... Click 'Details' for replacement.
12.873000A/R0
Details 23532556 Cylinder Kit; 15:1 TLC Bainitic Liner; 3.5mm Ring; S50/60
Superceded... Click 'Details' for replacement.
12.87300060
Details 23516681 Skirt, Crosshead Piston; (Roc) 12.8730001$68.140
Details View Images 8929013 Seal, Crevice 12.8730001$2.5112
Details 8929087 Pin, Piston 12.8730001$28.190
Details View Images 8929176 Seal, D-Ring 12.8730002$4.6412
Details View Images 8929337 Bolt, M14 X 1.5 X 60; 12Point 12.8730002$2.7914
Details View Images 8929845 Ring, Piston Bottom; Keystone 12.8730001$7.899
Details 23504941 Ring, Top; 3.5mm Keystone 12.8730001$10.860
Details View Images 23504942 Bushing, Top Piston Dome; 3 Piece 12.8730001$13.823
Details View Images 23515500 Ring, Piston Oil Control; Crosshead Piston 12.8730001$9.841
View Images 23519558 Bearing, Piston; (Lower); Pressure Fit; S50/60 (OBSOLETE) 12.8730002OBSOLETE2
Details View Images 23529379 Expander, Oil Control Ring; Spr Piston 12.8730001$4.251
4PM037E Skid 12.87300010
23529368 Dome Assembly; 15:1 Crosshead Piston 12.87300010
23531502 Liner, Cylinder; Bainitic; 12L (OBSOLETE) 12.8730001OBSOLETE0
Details View Images 8929130 Gasket, Accessory Cover 12.8730002$1.7513
Details View Images 8929299 Gasket, Front Accessory 12.8730002$3.2017
Details View Images 8929529 Gasket, Turbo Exhaust Inlet 12.8730001$2.0428
Details View Images 23515145 Gasket; (1.5040) 12.8730001$1.7632
Details View Images 23517875 Gasket, Air Intake Manifold 12.8730003$4.8110
Details View Images 23533983 Gasket, 3 Piece Exhaust Manifold; SST Thermoglide 12.8730003$5.806
Details View Images 5132155 Seal, Thermostat
Superceded... Click 'Details' for replacement.
12.8730002161
Details View Images 5150193 Gasket, Fuel Pump To Drive Assembly; (5.1010) 12.8730001$0.73220
Details View Images 5182977 Ring Seal; (3.3055) 12.8730001$0.3018
Details View Images 8929253 Seal Ring, 0.139" X 4.609" I.D.; (2.2280) 12.8730002$4.4515
Details View Images 8929285 Gasket, Turbo Oil Drain Tube 12.8730001$0.7116
Details View Images 8929302 Gasket; 4 Hole; (4.5007) 12.8730001$0.568
Details View Images 8929740 Seal Ring, 0.134 X 0.074 X 0.480 I.D. 12.8730003$1.338
Details View Images 23505248 Gasket, Fuel Pump 12.8730001$1.3512
Details View Images 23521894 Seal, Camshaft Thrust Plate To Cylinder Head 12.8730001$4.179
Details View Images 23521935 Seal, Camshaft Thrust Plate 12.8730001$4.5410
Details View Images 23522975 Seal, Front Camshaft Cap 12.8730001$1.453
Details View Images 23528491 Seal, Camshaft Thrust Plate Perimeter 12.8730001$6.574
Details View Images 5141452 Seal Ring; (3.4143) 12.8730001$1.2914
Details View Images 8929280 Seal Ring 12.8730002$1.9334
Details View Images 8929289 Seal Ring 12.8730002$2.7615
Details View Images 8929340 O-Ring, By-Pass Filter 12.8730001$1.2322
Details View Images 8929341 O-Ring, Oil Filter 12.8730001$1.2527
Details View Images 8929342 O-Ring, Oil Filter Adaptor; (Figure "8") 12.8730001$2.2814
Details View Images 8929347 Gasket, To Block 12.8730002$1.3221
Details View Images 8929348 Gasket 12.8730001$2.2313
Details View Images 23505891 Seal Ring, Oil Pump Outlet 12.8730001$1.0113
Details View Images 23505892 Seal Ring, Oil Pump Inlet 12.8730001$1.1212
Details View Images 23508392 Seal Ring 12.8730004$2.3443
Details View Images 23532850 Seal Ring, By-Pass Filter Adaptor 12.8730001$2.999
Details View Images 23521111 Seal 12.8730002$1.908
Details View Images 5117269 Gasket 12.8730002$0.6416
Details View Images 8929158 Seal Ring, 0.139 X 5.359 I.D.; Round 12.8730001$3.7527
Details View Images 8929344 Gasket, To Pump; (4.1520) 12.8730002$0.83167
Details View Images 8929347 Gasket, To Block 12.8730001$1.3221
Details View Images 8929510 Seal Ring, Cover 12.8730001$2.26167
Details View Images 23505024 Seal, O-Ring; Water Pump Cover; Square Cut 12.8730001$1.5819
Details View Images 23505992 Gasket, Oil Inlet Tube To Pump 12.8730001$0.683
Details View Images 23520377 Seal Ring; W/Square Cut 12.8730001$1.9270
23532045 Gasket, Cylinder Head; High Pressure 12.87300010
Details View Images 8929878 Thermostat Assembly; 190 Deg. Opening Temp.
Superceded... Click 'Details' for replacement.
12.873000216
Details View Images 8929690 Bearing Set, Std. 12.8730007$5.56115
8929086 Shell, Camshaft Bearing; Half 12.87300020
Details 23527000 Low N-Ox Instruction Envelope; S60 12.8730001$7.284
Details View Images 23530768 Bolt, M16 2.0 X 1.75; Large Hex 10.9; (12.9001) 12.87300038$2.47338
End of Detroit Diesel 60 Series Catalog
