Series 4000 Detroit Diesel Engines

TURBOCHARGER - group 3.5001

S4000-Pg81-94.jpg - Diagram
Page: 82
Part No. Description Group Ref#8V12V16V20V Price QOH
Details 23540170 Charge Air Kit, w/50hz Turbo
Superceded... Click 'Details' for replacement.
3.5001A/RA/RA/RA/R0
Details 5240201405 Turbocharger, 1.23 A/R BTV8507
Superceded... Click 'Details' for replacement.
3.5001144440
Details View Images 5136306 Clamp, 3-1/8" - 4-3/16" 3.500112121212$15.826
Details View Images 11505299 Bolt, M10x1.5x30mm 3.50018888$1.4516
Details 23526526 Bolt, M10x1.5x40 3.50018888$15.330
Details 23526527 Bolt, M10x1.5x50 3.50018888$26.000
Details View Images 23540064 Collector, Charge Air L.B. 3.5001221111$523.792
Details 23540065 Collector, Charge Air R.B. 3.5001201111$522.450
Details 23540068 Tube, Charge Air L.B. 3.50011111$154.150
Details 23540069 Tube, Charge Air R.B. 3.50011111$124.140
Details View Images 23540072 O-Ring, 6"x0.21 3.50012222$29.7710
Details View Images 5240980281 Hose 3.50016666$106.410
Details 5240980343 Air Inlet Housing 3.50011111$2,856.580
Details 5241420680 Gasket, Turbo Mounting Base 3.5001124444$32.870
Details View Images 5241870380 Gasket 3.500174444$1.761
Details View Images 5269870235 Seal, CAC 3.50011111$38.870
Details 23540171 Turbocharger Kit
Superceded... Click 'Details' for replacement.
3.5001A/RA/RA/RA/R0
Details 5260200805 Turbocharger, 1.08 A/R BTV7507
Superceded... Click 'Details' for replacement.
3.5001144440
Details View Images 0289976148 O-Ring, 150x5.2 3.50012222$22.950
Details View Images 11505299 Bolt, M10x1.5x30mm 3.50018888$1.4516
Details View Images 23517962 Clamp, 3.5"-4" Hose 3.500112121212$14.244
Details 23526526 Bolt, M10x1.5x40 3.50018888$15.330
Details 23526527 Bolt, M10x1.5x50 3.50018888$26.000
Details View Images 23540064 Collector, Charge Air L.B. 3.5001221111$523.792
Details 23540065 Collector, Charge Air R.B. 3.5001201111$522.450
Details View Images 23540070 Tube, Charge Air L.B. 3.50011111$220.331
Details View Images 23540071 Tube, Charge Air R.B. 3.50011111$220.330
Details View Images 5240980281 Hose 3.50016666$106.410
Details 5240980343 Air Inlet Housing 3.50011111$2,856.580
Details 5241420680 Gasket, Turbo Mounting Base 3.5001124444$32.870
Details View Images 5241870380 Gasket 3.500174444$1.761
Details View Images 5269870235 Seal, CAC 3.50011111$38.870
GROUP 3.5001 CONTINUED ON NEXT PAGE.
