| Part No. | Description | Group | Ref# | 6V | 8V | 12V | 16V | Price | QOH | |
|---|---|---|---|---|---|---|---|---|---|---|
| Note: Quantities For Oil Coolers And Associated Parts On This Page Are Per Oil Cooler, Not By Engine Size. | ||||||||||
| Details | 8547552 | Core Assy., Oil Cooler - Engine (32 Plate) | 4.4001 | 01 | 1 | $1,549.26 | 49 | |||
Details
|
8547237 | Core Assy., Oil Cooler - Engine (24 Plate) | 4.4001 | 01 | 1 | $1,707.28 | 7 | |||
| Details | 5150155 | Gasket, Oil Cooler Core Inner Superceded... Click 'Details' for replacement. | 4.4030 | 002 | 1 | 1 | 0 | |||
|
Details
|
8926782 | Gasket, Oil Cooler Core Inner (4.4115) | 4.4030 | 002 | 1 | 1 | $6.18 | 18 | ||
|
Details
|
23501587 | Gasket, Oil Cooler Core Outer (Element To Plate) | 4.4040 | 003 | 1 | 1 | $10.01 | 14 | ||
| Details | 23511304 | Gasket, Oil Cooler Core Outer Superceded... Click 'Details' for replacement. | 4.4040 | 003 | 1 | 1 | 12 | |||
|
Details
|
8925731 | Gasket, Oil cooler core Outer | 4.4040 | 003 | 1 | $29.06 | 5 | |||
| Details | 5117690 | Housing, Oil Cooler - Engine | 4.4050 | 004 | A/R | A/R | $613.47 | 0 | ||
| Details | 5126628 | Housing, Oil Cooler - Engine | 4.4050 | 004 | A/R | A/R | $601.09 | 40 | ||
|
Details
|
5106123 | Housing, Oil Cooler - Engine | 4.4050 | 004 | A/R | A/R | $1,094.21 | 13 | ||
| Details | 5100908 | Adaptor, 2.50" Dia., 1/4" Pt. | 4.4050 | 00 | A/R | A/R | $22.51 | 0 | ||
| Details | 187953 | Bolt, 5/16"-18 X 4 1/2" (12.9001) | 4.4050 | 00 | A/R | A/R | $26.90 | 0 | ||
|
Details
|
186274 | Bolt, 5/16"-18 X 5" (12.9001) | 4.4050 | 005 | A/R | A/R | $2.42 | 89 | ||
|
Details
|
455971 | Bolt, 5/16"-18 X 5 1/2" (12.9001) | 4.4050 | 00 | A/R | A/R | $2.54 | 30 | ||
|
Details
|
103320 | Lockwasher, 5/16" (12.9200) | 4.4050 | 006 | A/R | A/R | $0.07 | 100+ | ||
| Details | 5101742 | Cover, Oil Cooler Housing (Front) | 4.4060 | 00 | A/R | A/R | $436.79 | 43 | ||
|
Details
|
5117733 | Cover, Oil Cooler Housing (Bottom) (1.1060) | 4.4060 | 00 | A/R | A/R | $31.10 | 16 | ||
| 8927273 | Cover & Valve Assy., Oil Cooler Housing (OBSOLETE) | 4.4060 | 00 | A/R | A/R | OBSOLETE | 0 | |||
|
Details
|
8923847 | Plug, 1/4" Pipe (1.2001) Superceded... Click 'Details' for replacement. | 4.4060 | 00 | A/R | A/R | 100+ | |||
| Details | 272545 | Bolt, 5/16"-18 X 5 1/4" (12.9001 | 4.4060 | 00 | A/R | A/R | $2.30 | 0 | ||
|
Details
|
446597 | Bolt, 5/16"-18 X 6 1/2" (12.9001) | 4.4060 | 00 | A/R | A/R | $5.19 | 22 | ||
|
Details
|
180737 | Bolt, 5/16"-18 X 7" (12.9001) | 4.4060 | 00 | A/R | A/R | $5.26 | 18 | ||
|
Details
|
5155596 | Washer, 5/16 Copper (12.9190) | 4.4060 | 00 | A/R | A/R | $1.97 | 100+ | ||
|
Details
|
23501589 | Gasket, Oil Cooler Housing Cover (4.4040) | 4.4061 | 00 | 1 | 1 | $8.95 | 21 | ||
| Details | 23511304 | Gasket, Oil Cooler Housing Cover (4.4030) Superceded... Click 'Details' for replacement. | 4.4061 | 00 | 1 | 1 | 12 | |||
|
Details
|
5144703 | Gasket, Oil Cooler Housing Cover (5.5050) | 4.4061 | 00 | A/R | A/R | $19.45 | 2 | ||
| Details | 5117680 | Adaptor, Oil Cooler | 4.4110 | 007 | A/R | A/R | $624.01 | 8 | ||
|
Details
|
8925411 | Adaptor, Oil Cooler | 4.4110 | 007 | A/R | A/R | $279.34 | 6 | ||
| GROUP 4.4110 CONTINUED ON NEXT PAGE | ||||||||||
