Series 149 Detroit Diesel Engines

ELECTRONIC INJECTOR CONTROLS
- groups: 2.1700 - 2.1704

2.1525 - 2.1745 Electronic Injector Controls.jpg - Diagram
Page: 64
Part No. Description Group Ref#8V12V16V20V Price QOH
Details 23515115 Harness, Injector Wiring R.B.r.; DDEC 3 2.170000A/RA/RA/RA/R$343.320
Details View Images 23515117 Harness, Injector Wiring R.B.r.; DDEC 3 2.170000A/RA/RA/RA/R$478.871
Details 23503006 Harness, R.B. Front; L.B. Rear; (Long) 2.170000A/RA/RA/RA/R$376.670
Details 25C069FR Bolt, 1/4"-20 X 0.69" 2.170000A/RA/RA/RA/R$2.790
Details View Images 5104089 Bolt, 1/4"-20 X 1/2"; W/Seal Patch; (12.9001) 2.170000A/RA/RA/RA/R$0.966
Details View Images 186289 Bolt, 3/8"-16 X 5.00" 2.170000A/RA/RA/RA/R$6.12-1
Details View Images 186625 Bolt, 5/16"-18 X 7/8" 2.170000A/RA/RA/RA/R$0.942
Details View Images 5163538 Clip, 3/16" Tube; (7.8320) 2.170000A/RA/RA/RA/R$3.130
Details View Images 2488022 Clip, 3/8" Bolt; (12.8554) 2.170000A/RA/RA/RA/R$1.738
Details View Images 5101020 Strap, Nylon; (2.5255) 2.170000A/RA/RA/RA/R$0.710
Details View Images 120393 Washer, 5/16" 2.170000A/RA/RA/RA/R$0.33307
Details 23504917 Harness Interface; 8V; (Option Type #'s 217, 238, 439) 2.1703001$455.350
Details 23511751 Harness Interface; 20V; (Option Type #281) 2.1703001$2,380.860
Details 23504404 Harness, Sensor 2.170400A/RA/RA/RA/R$870.850
Details 23513065 Harness, Sensor 2.170400A/RA/RA/RA/R$2,526.630
Details 23511682 Harness, Sensor Wiring; DDEC 2.170400A/RA/RA/RA/R$1,324.930
Details 23515121 Harness, Sensor Wiring; DDEC 3 2.170400A/RA/RA/RA/R$2,284.700
Details 23515123 Harness, Sensor Wiring; DDEC 3 2.170400A/RA/RA/RA/R$1,095.630
Details 23507827 Harness, Sensor Wiring; DDEC V14 2.170400A/RA/RA/RA/R$533.040
Details 23507828 Harness, Sensor Wiring; DDEC V14 2.170400A/RA/RA/RA/R$1,143.880
Details View Images 23515122 Harness, Sensor Wiring 2.170400A/RA/RA/RA/R$514.570
Details 12010996 Connector, DDEC Wire Harness; 1 Female Terminal 2.1704001111$1.620
Details View Images 12015384 Connector, Turbo Boost Sensor 2.1704001111$3.762
Details 12015791 Connector, Female; 1 Way Weather Pack 2.1704001111$2.740
Details View Images 12034400 Connector; (2.6657) 2.1704001111$21.6413
Details View Images 12162193 Connector, DDEC Wire Harness 2.1704001111$4.010
Details 12048086 Seal, Connector; Metri-Pack; (Red) 2.1704001111$0.310
Details 12052648 Connector & Seal 2.1704001111$1.140
Details 12052845 Secondary Lock 2.1704001111$1.400
Details View Images 12110293 Connector Assembly, 3 Way; 150 Series; Metri-Pack; Female 2.1704001111$6.281
Details 12129615 Connector Assembly, 3 Way; 150 Series; Metri-Pack; Male 2.1704001111$2.040
Details 23508934 Connector, Deutsch 2.1704001111$22.510
Details 23516834 Plug 2.1704001111$12.690
Details 23516839 Socket 2.1704001111$1.830
Details View Images 12162144 Connector & Seal Assembly, 4 Way; 150 Series; Metri-Pack;
Female
2.1704001111$3.606
Details 12162182 Connector Assembly, 3 Way; 150.2 Series; Metri-Pack;
Female
2.1704001111$7.050
GROUP 2.1704 CONTINUED ON NEXT PAGE
