Series 60 Detroit Diesel Engines

BASIC ENGINE OVERHAUL KIT CONTENTS FOR
PART #23532574 - group: 12.8730

12.8730 Basic Engine Overhaul Kits.jpg - Diagram
Page: 321
Information   Abbreviations   Alphabetical Index   Group Index
Part No. Description Group Ref#11.1L12.7L14.0L Price QOH
Details 23532574 Basic Overhaul Kit; 15:1 C/R; Articulated STL Piston;
TLC Bianitic Liner
Superceded... Click 'Details' for replacement. 		12.873000A/R0
Details 23532561 Cylinder Kit; 15:1 C/R; TLC Bainitic Liner; Bushless
Articulated STL
Superceded... Click 'Details' for replacement. 		12.873000611
Details 8929013 Seal, Crevice 12.8730001$19.5112
Details View Images 8929176 Seal, D-Ring 12.8730002$18.8624
Details 8929844 Ring, Piston Top; 2.5mm Keystone 12.8730001$25.330
Details View Images 8929845 Ring, Piston Bottom; Keystone 12.8730001$20.809
Details View Images 23506222 Bolt, M8 X 1.25 X 20mm; 12 Point Head 12.8730001$3.6730
Details View Images 23515500 Ring, Piston Oil Control; Crosshead Piston 12.8730001$20.261
Details View Images 23521781 Retainer, Steel Piston Pin 12.8730002$1.1215
Details View Images 23525168 Pin, Piston; 22mm I.D. 12.8730001$54.796
Details 23528493 Nozzle Assembly, Piston Cooling; Articulated 12.8730001$27.4123
Details View Images 23529379 Expander, Oil Control Ring; Spr Piston 12.8730001$9.651
23530600 Dome & Skirt Assembly, Piston; Bushless STL; 15:1; 12L 12.87300010
23531502 Liner, Cylinder; Bainitic; 12L (OBSOLETE) 12.8730001OBSOLETE0
Details View Images 8929130 Gasket, Accessory Cover 12.8730002$11.615
Details View Images 8929299 Gasket, Front Accessory 12.8730002$12.4112
Details View Images 8929529 Gasket, Turbo Exhaust Inlet 12.8730001$4.4247
Details View Images 23515145 Gasket; (1.5040) 12.8730001$11.7645
Details View Images 23517875 Gasket, Air Intake Manifold 12.8730003$13.0514
Details View Images 23533983 Gasket, 3 Piece Exhaust Manifold; SST Thermoglide
Superceded... Click 'Details' for replacement. 		12.873000316
Details 5132155 Seal, Thermostat
Superceded... Click 'Details' for replacement. 		12.8730002100+
Details View Images 5150193 Gasket, Fuel Pump To Drive Assembly; (5.1010) 12.8730001$5.37100+
Details View Images 5182977 Ring Seal; (3.3055) 12.8730001$0.4390
Details View Images 8929253 Seal Ring, 0.139" X 4.609" I.D.; (2.2280) 12.8730002$8.5712
Details View Images 8929285 Gasket, Turbo Oil Drain Tube 12.8730001$1.1034
Details View Images 8929302 Gasket; 4 Hole; (4.5007) 12.8730001$1.939
Details View Images 8929740 Seal Ring, 0.134 X 0.074 X 0.480 I.D. 12.8730003$2.119
Details View Images 23505248 Gasket, Fuel Pump 12.8730001$2.1435
Details 23521894 Seal, Camshaft Thrust Plate To Cylinder Head 12.8730001$15.4711
Details View Images 23521935 Seal, Camshaft Thrust Plate 12.8730001$12.256
Details View Images 23522975 Seal, Front Camshaft Cap 12.8730001$3.435
Details View Images 23528491 Seal, Camshaft Thrust Plate Perimeter 12.8730001$19.684
Details 5141452 Seal Ring; (3.4143) 12.8730001$1.667
Details View Images 8929280 Seal Ring 12.8730002$7.5337
Details 8929289 Seal Ring 12.8730002$8.7711
Details View Images 8929340 O-Ring, By-Pass Filter 12.8730001$2.3722
Details View Images 8929341 O-Ring, Oil Filter 12.8730001$2.7427
Details View Images 8929342 O-Ring, Oil Filter Adaptor; (Figure "8") 12.8730001$6.5115
Details View Images 8929347 Gasket, To Block 12.8730002$1.4910
Details View Images 8929348 Gasket 12.8730001$5.5414
Details View Images 23505891 Seal Ring, Oil Pump Outlet 12.8730001$4.0816
Details View Images 23505892 Seal Ring, Oil Pump Inlet 12.8730001$3.3216
Details View Images 23508392 Seal Ring 12.8730004$5.2625
Details View Images 23532850 Seal Ring, By-Pass Filter Adaptor 12.8730001$8.374
Details View Images 23521111 Seal 12.8730002$5.147
Details View Images 5117269 Gasket 12.8730002$1.1731
Details 8929158 Seal Ring, 0.139 X 5.359 I.D.; Round 12.8730001$14.6620
Details View Images 8929344 Gasket, To Pump; (4.1520) 12.8730002$2.51100+
Details View Images 8929347 Gasket, To Block 12.8730001$1.4910
Details View Images 8929510 Seal Ring, Cover 12.8730001$24.98100+
Details View Images 23505024 Seal, O-Ring; Water Pump Cover; Square Cut 12.8730001$4.0738
Details 23505992 Gasket, Oil Inlet Tube To Pump 12.8730001$2.018
Details View Images 23520377 Seal Ring; W/Square Cut 12.8730001$7.3155
23532045 Gasket, Cylinder Head; High Pressure 12.87300010
Details 8929878 Thermostat Assembly; 190 Deg. Opening Temp.
Superceded... Click 'Details' for replacement. 		12.87300026
Details View Images 8929690 Bearing Set, Std. 12.8730007$18.8660
8929086 Shell, Camshaft Bearing; Half 12.87300020
Details 23527000 Low N-Ox Instruction Envelope; S60 12.8730001$9.474
Details View Images 23530768 Bolt, M16 2.0 X 1.75; Large Hex 10.9; (12.9001) 12.87300038$8.50100+
GROUP 12.8730 CONTINUED ON NEXT PAGE
