Series Inline 71 Detroit Diesel Engines

OVERHAUL GASKET KIT CONTENTS FOR PART # 5192922
- group: 12.8715

il71_5192922.jpg - Diagram
Page: 185
Information   Abbreviations   Alphabetical Index   Group Index
Part No. Description Group Ref#2IL3IL4IL6IL Price QOH
Details View Images 5192922 Gasket Kit, Engine Overhaul (Low Block) (4-71) 12.871500A/R$645.862
Details View Images 5103559 Gasket & Screen Assy., Blower Inlet (3.4025) 12.8715001$16.9941
Details View Images 23505525 Gasket, 3/8" Copper (12.9360) 12.8715004$0.9186
Details View Images 5174200 Gasket (OBSOLETE) 12.8715002OBSOLETE2
Details View Images 5150889 Gasket, Governor Cover 12.8715001$2.5420
Details 5150194 Gasket, Exhaust Manifold 12.8715002$12.588
Details 23508431 Seal Ring, Front Water Pump Outlet 12.8715001$1.8345
Details 5174202 Gasket (OBSOLETE) 12.8715002OBSOLETE2
Details View Images 105456 Gasket, 7/8" Copper (12.9360) 12.8715002$7.32100+
Details View Images 3290612 Gasket, Air Inlet Housing Shutdown (3.3030) 12.8715001$3.056
Details View Images 5121753 Gasket, Balance Weight Cover (1.7480) 12.8715001$8.429
Details View Images 5115657 Gasket, Blower (3.4010) 12.8715001$7.0910
Details View Images 5148810 Gasket, Blower Drive Support (1.7646) 12.8715001$4.02100+
Details View Images 5114726 Gasket, Blower End Plate Cover (3.4190) 12.8715002$5.8275
Details View Images 5150234 Gasket, Blower End Plate Cover (3.4190) 12.8715002$3.7641
Details View Images 5150900 Gasket, Breather Pipe (4.8020) 12.8715001$1.40100+
Details View Images 5150181 Gasket, Crankshaft Cover (1.3170) 12.8715001$7.3418
Details 23505518 Gasket, Cylinder Block End Plate (Front) (1.1030) 12.8715002$35.3219
Details View Images 5116357 Gasket, Cylinder Block Water Hole Cover (1.1070) 12.8715001$1.0922
Details View Images 5150044 Gasket, Cylinder Head Compression (1.2010) 12.8715001$149.6815
Details View Images 5123812 Gasket, Cylinder Head Governor Cover Hole (1.7060) 12.8715004$1.44100+
Details View Images 5150052 Gasket, Engine Lifter Bracket (1.2090) 12.8715002$1.9342
Details 8928967 Gasket, Flywheel Housing (1.5010) 12.8715001$28.687
Details View Images 23515145 Gasket, Flywheel Housing (Large) (1.5040) 12.8715002$11.7651
Details View Images 5150055 Gasket, Flywheel Housing (Small Cover) (1.5010) 12.8715002$1.5855
Details View Images 5104507 Gasket, Flywheel Housing (Small) (1.5060) 12.8715001$4.1770
Details View Images 5150193 Gasket, Fuel Pump (Pump To Engine) (5.1010) 12.8715002$5.37100+
Details View Images 5161003 Gasket, Fuel Pump Valve (2.2180) 12.8715001$0.84100+
Details View Images 5150246 Gasket, Governor Drive Housing (2.7010) 12.8715002$3.9393
Details View Images 8922593 Gasket, Governor Spring Cover (2.7700) 12.8715001$4.0933
Details View Images 5150890 Gasket, Governor Weight Housing (2.7530) 12.8715002$0.97100+
Details View Images 5165221 Gasket, Governor Weight Housing Cap (2.7515) 12.8715001$0.9355
Details View Images 5132117 Gasket, Hand Hole Cover (1.1050) 12.8715004$6.38100+
Details View Images 5150154 Gasket, Oil Cooler Adaptor (4.4115) 12.8715002$2.4913
Details View Images 5175882 Gasket, Oil Cooler Adaptor (4.4115) 12.8715002$2.2927
Details 5151190 Gasket, Oil Cooler By-Pass (5.2180) 12.8715001$2.98100+
Details View Images 23501591 Gasket, Oil Cooler Cover (4.4030) 12.8715001$3.93100+
Details View Images 8923223 Gasket, Oil Cooler Outlet (4.4040) 12.8715001$6.8614
Details View Images 5153902 Gasket, Oil Inlet Pipe (4.1590) 12.8715002$1.0418
Details View Images 5151370 Gasket, Oil Pad (1.87" B.C.) (4.1300) 12.8715003$0.5965
Details View Images 5153313 Gasket, Oil Pad (2.12" B.C.) (4.1300) 12.8715002$0.63100+
Details View Images 5150116 Gasket, Oil Pan (Cast Iron) (4.7030) 12.8715001$11.2623
Details View Images 840277 Gasket, Oil Pan Drain Plug (4.7090) 12.8715003$7.32100+
Details View Images 5153627 Gasket, Oil Pump Inlet (4.1520) 12.8715001$2.9562
Details 64444 Gasket, Oil Strainer Housing (4.2040) 12.8715001$2.760
Details 64446 Gasket, Oil Strainer Retainer (4.2100) 12.8715001$1.730
Details View Images 5169478 Gasket, Thermostat Housing (2.2110) 12.8715002$0.9771
Details View Images 23506469 Gasket, Water Outlet Manifold (5.2010) 12.8715004$0.97100+
Details View Images 5150188 Gasket, Water Pump Body Cover (5.1236) 12.8715001$1.0975
Details View Images 5150191 Seal Ring, Fresh Water Pump Outlet Packing (5.1220) 12.8715002$2.21100+
Details View Images 5152148 Washer, 3/8" Copper (2.4050) 12.8715001$0.78100+
GROUP 12.8715 CONTINUED ON NEXT PAGE
