Series 4000 Detroit Diesel Engines

TURBOCHARGER - groups 3.5324 - 3.5330

S4000-Pg81-94.jpg - Diagram
Page: 88
Part No. Description Group Ref#8V12V16V20V Price QOH
Details 5261400514 Elbow, 90 Deg. Exhaust 3.5324A/RA/RA/RA/R$3,323.600
Details 0014909865 Pipe, Exhaust Bellows 3.5324A/RA/RA/RA/R$2,869.100
Details 0001400182 Bellows, Turbocharger Exhaust Tube 3.5324A/RA/RA/RA/R$1,109.880
5591426615 Flange 3.5324A/RA/RA/RA/R0
Details 5361420480 Gasket 3.5324A/RA/RA/RA/R$28.960
Details 5361420012 Clamp Half 3.5324A/RA/RA/RA/R$72.060
Details 000908014009 Plug 3.5324A/RA/RA/RA/R$7.280
Details 000939010115 Stud, M10x45 3.5324A/RA/RA/RA/R$1.340
Details 200931010002 Bolt, M10x50 3.5324A/RA/RA/RA/R$8.020
Details View Images 000933010093 Bolt, M10x35 Hex 3.5324A/RA/RA/RA/R$1.6114
Details 000933010116 Bolt, M10x45 Hex 3.5324A/RA/RA/RA/R$0.800
Details View Images 007603014103 Washer, A14x18 3.5324A/RA/RA/RA/R$1.190
Details View Images 200433010500 Washer 3.5324A/RA/RA/RA/R$3.040
Details View Images 000125010524 Washer, A10.5 3.5324A/RA/RA/RA/R$0.270
Details View Images 000934010007 Nut, Hex 3.5324A/RA/RA/RA/R$0.370
Details 200934010000 Nut, M10 Hex 3.5324A/RA/RA/RA/R$4.070
Details View Images 5244920181 Seal Ring, 4.562 Dia. Exh. 3.53253A/RA/RA/RA/R$35.890
Details 5261420115 Flange, Sealing 3.5325A/RA/RA/RA/R$71.300
Details View Images 5241420540 Bracket 3.5330A/RA/RA/RA/R$81.280
Details 5241420072 Spacer
Superceded... Click 'Details' for replacement.
3.5330A/RA/RA/RA/R0
Details 23530792 Kit, Exhaust Outlet Spacer 3.5330A/RA/RA/RA/R$4.420
Details View Images 000933010095 Bolt, M10x50 Hex 3.53301111$0.840
Details View Images 11506101 Nut, M10x1.5 3.533021111$0.556
Details 5511531250 Spacer, 30mm 3.53301111$2.910
23540038 Spacer, Exhaust Outlet (OBSOLETE) 3.5330A/RA/RA/RA/ROBSOLETE0
Details 23540101 Spacer, 30mm
Superceded... Click 'Details' for replacement.
3.5330A/RA/RA/RA/R0
GROUP 3.5330 CONTINUED ON NEXT PAGE.
