John Deere Parts Catalog

Industrial Engine Model 6076D
Litre Engine
7.6L 466 (7668cc) OHV Diesel L6 116mm Bore

135.jpg - Diagram
Page: 135
Part No. Description Group Ref#Qty. Price QOH
Details View Images PC-R130573 Intake Valve Manifold Gasket; From Serial # 500,000; W/Intake Valve Seat
Manifolds R89790, R115393, R130718, R131473, R131651, R131657,
R132290, R134429
Int/Exh Mfld.03$5.700
Details View Images PC-R130573 Intake Valve Manifold Gasket; To Serial # 499,999; W/Intake Valve Seat
Manifolds R89790, R96518
Int/Exh Mfld.03$5.700
Details View Images PC-R26058 Crankshaft Front Cover Gasket; To Serial # 499,999 Camshaft01$3.511
Details PC-R53901 Washer, Control Valve Seal To Housing; Pump Housing Codes 1601, 1604,
1637, 1688, 1689; Filter & Line Codes 3511, 3512
Fuel Sys.01$2.220
Details PC-R53899 Washer, Fuel Filter & Lines; Fuel Filter Codes 3511, 3512 Fuel Sys.01$2.200
Details PC-R84472 Washer, Injector Nozzle; Fuel Inj. Nozzle & Line Codes 1604, 1610, 1616,
1650; .290" X .715" X .079"
Fuel Sys.166$0.630
Details PC-R84472 Washer, Injector Nozzle; Nozzle Codes 1610, 1626, 1637, 1640, 1650;
To Serial # 586,899; .290" X .715" X .079"
Fuel Sys.166$0.630
Details PC-R79604 Fuel Injector Nut, Injector Pump; Line Codes 1601, 1604, 1623, 1637, 1644,
1652, 1667, 1680, 1683, 1686, 1688; To Serial # 499,999
Fuel Sys.156$2.200
Details View Images PC-R51936 Washer Type Seal, Leak-Off & Return Line Seals; Nozzle Codes 1604,
1610, 1616, 1637, 1650
Fuel Sys.1313$0.940
Details View Images PC-R51936 Washer Type Seal, L.H. & R.H.; Aux. Drive Line Seals Fuel Sys.013$0.940
Details PC-R77551 O-Ring, Leak-Off Fitting To Nozzle; Nozzle Codes 1601, 1604, 1610, 1615,
1616, 1623, 1637, 1644, 1650; Viton
Fuel Sys.06$0.410
Details PC-R86743 O-Ring, Outer Coupling; Manifold Code 1726 Fuel Sys.01$2.750
Details PC-R71225 Water Pump Impeller; Water Pump Code 2032; W/Pump Housing Marked R83561 Cooling Sys.11$78.000
Details PC-JD10329 Ball Bearing, Water Pump Fan Hub Shaft Bearing Cooling Sys.62$31.430
Details PC-JD10363 Ball Bearing, Water Pump Gear Driven Front Bearing; Water Pump Code 2032;
W/Pump Housing Marked R83561
Cooling Sys.41$13.400
Details PC-JD10362 Ball Bearing, Water Pump Gear Driven Rear Bearing; Water Pump Code 2032;
W/Pump Housing Marked R83561
Cooling Sys.31$20.370
Details PC-R71361 Water Pump Inlet Gasket; W/Pump Housing Marked R83561; To Serial # 499,999 Cooling Sys.01$0.940
PC-RE39134 Water Pump Oil Seal; Water Pump Code 2032; W/Pump Housing Marked R83561;
To Serial # 499,999
Cooling Sys.810
Details PC-R72328 O-Ring, Water Tube To Thermostat Housing Seal; Water Pump Code 2030;
Thermostat Housing Code 3905
Cooling Sys.273$0.890
Details PC-R72328 O-Ring, Water Tube To Thermostat Housing Seal; 6076D Engines; Water Pump
Codes 2030, 2039; Thermostat Housing Codes 3905, 3909
Cooling Sys.273$0.890
INDUSTRIAL ENGINE 6076D CONTINUED ON NEXT PAGE
