John Deere Parts Catalog

Industrial Engine Model 3179D & 3029D
Standard Engine
2.9L 179 OHV Diesel L3 4.1929 Bore

38.jpg - Diagram
Page: 38
Part No. Description GroupRef#Qty. Price QOH
Details PC-R90658 Exhaust Valve Manifold Gasket Int/Exh Mfld.03$1.100
Details View Images PC-R81275 Air Intake Valve Gasket Int/Exh Mfld.01$0.891
Details View Images PC-T20273 Timing Gear Cover Gasket, Access Cover Camshaft01$1.442
Details View Images PC-R97454 Timing Gear Cover Gasket, Front Cover Camshaft01$3.360
Details PC-T20073 Lifter, Camshaft Camshaft06$8.080
Details PC-AR89564 Fuel Injector Nozzle Fuel Sys.163$40.090
Details PC-R79605 Fuel Injector Seal, Fuel Line Connection; Nozzle Marked 27333;
9.270MM X 13.600MM X 5.080MM
Fuel Sys.143$1.3714
Details PC-R79604 Fuel Injector Nut; W/Injector Marked 27333 Fuel Sys.153$1.480
Details PC-R34766 Clamp; Pump Code 3707 Fuel Sys.02$0.380
Details View Images PC-R51936 Washer Type Seal, Leak-Off & Return Line Seals; W/Nozzle Marked 27333 Fuel Sys.136$0.630
Details View Images PC-R97350 Fuel Transfer Pump Gasket Fuel Sys.01$0.451
PC-9448-40979 Water Pump Repair/Rebuild Kit; W/Pump Housing Marked R52009 Cooling Sys.010
Details PC-R55405 Water Pump Housing Gasket; W/Pump Housing Marked R100812, R127918;
Pump Housing To Back Cover
Cooling Sys.91$3.150
Details PC-R55406 Water Pump Housing Gasket; W/Pump Housing Marked R55130;
To Serial # 498,345; Pump Housing To Back Cover
Cooling Sys.91$5.360
Details PC-R55406 Water Pump Housing Gasket; W/Pump Housing Marked R55164; From Serial #
498,346; Pump Housing To Back Cover
Cooling Sys.91$5.360
Details View Images PC-R97455 Water Pump Housing Gasket; W/Pump Housing Marked R73604, R91724, R91810;
Pump Housing To Back Cover
Cooling Sys.91$2.460
Details View Images PC-T20243 Water Pump Mounting Gasket; W/Pump Housing Marked R55130, R73604, R91810,
R100812, R122337, R127918; Pump To Block
Cooling Sys.101$1.110
Details PC-JD9448 Water Pump Shaft & Bearing Assembly; W/Cast Pulley; W/Pump Housing
Marked R55164
Cooling Sys.51$29.080
Details PC-AR61538 Thermostat; Thermostat Code 2208; 181 Deg. Cooling Sys.221$19.580
Details PC-T20219 Thermostat Gasket; Thermostat Housing Codes 3901 Marked R60256, T20218;
Thermostat Housing Codes 3909, 3910; Thermostat Cover Codes 2101, 2104,
3914 Marked R91165
Cooling Sys.211$0.523
Details PC-T20215 Thermostat Cover Gasket; Thermostat Cover Codes 2101, 2102; Thermostat
Housing Codes 2101, 2204, 3914; W/Housing Marked R91165
Cooling Sys.201$0.521
Details PC-R97351 Flywheel Housing Gasket, R.H.; Use W/Flywheel Housing SAE 4; W/2 Hole Mounting Cyl. Block01$6.380
Details PC-R97341 Oil Pan Gasket; Exc. Aluminum Oil Pan Cyl. Block01$8.510
Details View Images PC-R131794 Block To End Plate, Front Gasket; Front Plate Codes 3601, 3602, 3695 Cyl. Block01$11.470
INDUSTRIAL ENGINE 3179D & 3029D CONTINUED ON NEXT PAGE
