| Part No. | Description | Group | Ref# | 2IL | 3IL | 4IL | 6IL | Price | QOH | |
|---|---|---|---|---|---|---|---|---|---|---|
Details
|
5154403 | Lever, Governor Operating Shaft (A & B Engine) | 2.7280 | 23 | 1 | 1 | 1 | 1 | $151.91 | 2 |
|
Details
|
5154422 | Lever, Governor Operating Shaft (C & D Engine) | 2.7280 | 23 | 1 | 1 | 1 | $108.84 | 8 | |
|
Details
|
5150898 | Screw (Gap Adjusting), Governor Operating Shaft Lever | 2.7280 | 24 | 1 | 1 | 1 | 1 | $30.75 | 11 |
|
Details
|
120613 | Nut, 1/4"-28 Hex, Governor Operating Shaft Lever Screw (12.9120) | 2.7280 | 25 | 1 | 1 | 1 | 1 | $0.94 | 100+ |
|
Details
|
5185605 | Fork, Governor Operating Shaft | 2.7290 | 26 | 1 | 1 | 1 | 1 | $110.64 | 40 |
| 139013 | Screw, 1/4"-28 X 1/2" Set (12.9076) (OBSOLETE) | 2.7290 | 00 | 1 | 1 | 1 | 1 | OBSOLETE | 0 | |
|
Details
|
5150943 | Pin, Governor Operating Shaft Lever | 2.7300 | 27 | 1 | 1 | 1 | 1 | $43.02 | 20 |
|
Details
|
23504196 | Solenoid, Governor Operating (12 V.) (7.4519) | 2.7305 | 00 | 1 | 1 | 1 | $253.34 | 14 | |
|
Details
|
100001 | Bolt, 1/4"-28 X 3/4" (12.9001) | 2.7305 | 00 | 4 | 4 | 4 | $0.34 | 100+ | |
|
Details
|
120392 | Washer, 1/4" (12.9190) | 2.7305 | 00 | 4 | 4 | 4 | $0.96 | 34 | |
|
Details
|
103319 | Lockwasher, 1/4" (12.9200) | 2.7305 | 00 | 4 | 4 | 4 | $0.40 | 100+ | |
|
Details
|
120367 | Nut, 1/4"-28 (12.9120) | 2.7305 | 00 | 4 | 4 | 4 | $3.92 | 0 | |
|
Details
|
5150394 | Lever Assy., Governor Differential | 2.7310 | 28 | 1 | 1 | 1 | 1 | $146.27 | 26 |
|
Details
|
5150894 | Pin 25/32" L., Governor Differential Lever (2.7315) | 2.7310 | 29 | 1 | 1 | 1 | 1 | $19.45 | 15 |
| Details | 142583 | Retainer 13/64" Spring, Governor Differential Pin | 2.7310 | 00 | 1 | 1 | 1 | 1 | $1.48 | 100+ |
|
Details
|
5150941 | Washer, 21/64" Flat Governor Differential Lever Pin (2.7310) | 2.7310 | 30 | 1 | 1 | 1 | 1 | $1.09 | 75 |
|
Details
|
5100004 | Eye, Governor Link (2.9024) | 2.7312 | 00 | 1 | 1 | 1 | $12.02 | 2 | |
|
Details
|
181596 | Bolt, 5/16"-24 X 7/8" (12.9001) | 2.7312 | 00 | 1 | 1 | 1 | $0.97 | 3 | |
|
Details
|
114493 | Nut, 5/16"-24 Lock (2.7170) | 2.7312 | 00 | 1 | 1 | 1 | $1.75 | 25 | |
|
Details
|
5150894 | Pin 25/32" L., Governor Lever Differential | 2.7315 | 29 | 1 | 1 | 1 | 1 | $19.45 | 15 |
| To Identify Components Of The Carrier & Weight Assembly, Go To The GOVERNOR CARRIER & WEIGHT Section | ||||||||||
|
Details
|
5154501 | Riser, Governor Weight Bearing | 2.7380 | 00 | 1 | 1 | 1 | 1 | $102.79 | 8 |
|
Details
|
5154502 | Riser, Governor Weight Bearing | 2.7380 | 00 | 1 | 1 | 1 | $168.77 | 10 | |
|
Details
|
5154503 | Riser, Governor Weight Bearing | 2.7380 | 00 | 1 | 1 | 1 | 1 | $134.35 | 3 |
| To Identify The Governor Weights, Pins And Bearings, Go To The GOVERNOR CARRIER & WEIGHT Section | ||||||||||
|
Details
|
9437108 | Bearing .354" W., Governor Weight Riser Thrust | 2.7460 | 31 | 1 | 1 | 1 | 1 | $67.36 | 100+ |
|
Details
|
9424121 | Bearing, Governor Weight Shaft End | 2.7470 | 32 | 1 | 1 | 1 | 1 | $32.37 | 100+ |
|
Details
|
5150884 | Screw, Governor Weight Shaft End Bearing | 2.7470 | 33 | 1 | 1 | 1 | 1 | $24.79 | 14 |
|
Details
|
5150941 | Washer, Governor Weight Shaft End Bearing (2.7310) | 2.7470 | 00 | 1 | 1 | 1 | 1 | $1.09 | 75 |
|
Details
|
5150897 | Lockwasher, Governor Weight Shaft End Bearing | 2.7470 | 34 | 1 | 1 | 1 | 1 | $0.76 | 72 |
|
Details
|
5183268 | Cap, Governor Weight Housing | 2.7510 | 35 | 1 | 1 | 1 | 1 | $36.92 | 10 |
|
Details
|
5165221 | Gasket, Governor Weight Housing | 2.7515 | 36 | 1 | 1 | 1 | 1 | $0.93 | 56 |
|
Details
|
5176837 | Cover, Governor Weight Housing (Tapped) | 2.7520 | 00 | A/R | A/R | A/R | $46.62 | 13 | |
|
Details
|
5163514 | Cover, Governor Weight Housing | 2.7520 | 00 | 1 | 1 | 1 | $17.09 | 23 | |
|
Details
|
190910 | Bolt, 1/4"-20 X 2 3/8" (12.9001) | 2.7520 | 37 | 4 | 4 | 4 | $5.06 | 0 | |
|
Details
|
103319 | Lockwasher, 1/4" (12.9200) | 2.7520 | 38 | 4 | 4 | 4 | $0.40 | 100+ | |
| CONTINUE TO NEXT PAGE FOR GROUP 2.7530 | ||||||||||
